6003 2Z FAG

Net price:

2.925 €/pcs

Main warehouse:
On stock
6 pcs

External stock:
On stock
20 pcs

Next delivery:

2026-05-22 - 200 pcs

Product number:

6003 2Z

Brand:

FAG

Product name:

bearing

Sizes:

17X35X10

Replacements:
6003 2ZR*FAG

Inquiry Subscribe

Product details from catalogue

Drawings:

6003-2Z FAG


d Bore diameter 17 mm
D Outside diameter 35 mm
B Width 10 mm
Cr Basic dynamic load rating, radial 6.400 N
C0r Basic static load rating, radial 3.250 N
Cur Fatigue load limit, radial 162 N
nG Limiting speed 26.000 1/min
nϑr Reference speed 20.300 1/min
≈m Weight 39,5 g
da min Minimum diameter shaft shoulder 19 mm
Da max Maximum diameter of housing shoulder 33 mm
ra max Maximum fillet radius 0,3 mm
rmin Minimum chamfer dimension 0,3 mm
D2 Caliber diameter outer ring 30,8 mm
d1 Shoulder diameter inner ring 22,7 mm
Tmin Operating temperature min. -20 °C
Tmax Operating temperature max. 120 °C
f0 Calculation factor 14,3
Sealing Non-contact Shield on both sides 2Z
Cage steel sheet metal JN
Tolerance class Normal (PN) PN
Dimensional / heat stabilization Rings dimensional stabilized up to 120° SN
Lubricant ball bearing grease, low noise for D<=62mm GA14
Fill factor Standard
Radial internal clearance Group N (CN) CN
Bore type Cylindrical Z
