Product number:

GLCTE 40-XL

Brand:

Product name:

housing unit

Replacements:

GLCTE 40 GLCTE 08+GRAE 40NPPB

Inquiry Subscribe

GLCTE40-XL INA

Housing units GLCTE, two-bolt flanged housing units, cast iron, eccentric locking collar, P seals

Replacements: GLCTE40

d	Bore diameter	40 mm
L	Flange width	100 mm
H	Height flange	150 mm
U	Total height unit	46,3 mm
Cr	Basic dynamic load rating, radial	34.500 N
C0r	Basic static load rating, radial	19.800 N
Cur	Fatigue load limit, radial	1.030 N
≈m	Weight	1,27 kg
J	Distance fixing bore	119 mm
N	Fixing bore	14 mm
n	Number of screwing holes	2
A1	Thickness of flange	24 mm
A2	Distance raceway	13,5 mm
B1	Locking collar total width	43,8 mm
Q	Connection thread lubrication	M6
d3	Outside diameter eccentric locking collar	58 mm
