N 206 E-XL-TVP2-C3 FAG

Net price:

37.566 €/pcs

Main warehouse:
On stock
3 pcs

Product number:

N 206 E-XL-TVP2-C3

Brand:

FAG

Product name:

bearing

Sizes:

30X62X16

Suffixes:

E - növelt teherbírás

TVP2 - görgõn vezetett polyamid kosár

C3 - a csapágyhézag nagyobb a normálisnál


Replacements:
N 206 E-TVP2-C3

Inquiry Subscribe

Product details from catalogue

Drawings:

N206-E-XL-TVP2-C3 FAG

Cylindrical roller bearing N2..-E-TVP, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N2


d Bore diameter 30 mm
D Outside diameter 62 mm
B Width 16 mm
Cr Basic dynamic load rating, radial 46.000 N
C0r Basic static load rating, radial 37.500 N
Cur Fatigue load limit, radial 5.500 N
nG Grease Limiting speed for grease lubrication 13.900 1/min
nG Oil Limiting speed for oil lubrication 16.300 1/min
≈m Weight 0,205 kg
da diameter shaft shoulder 34 mm
Da diameter of housing shoulder 56 mm
ra1 max Maximum recess radius 1 mm
r1 min Minimum chamfer dimension 0,6 mm
s1 Axial displacement 1,4 mm
E Raceway diameter outer ring 55,5 mm
Tmin Operating temperature min. -30 °C
Tmax Operating temperature max. 120 °C
Cage Solid Window Cage made from PA66 TVP2
Tolerance class Normal (PN) PN
Change mark Increased Capacity Design E
Radial internal clearance Group 3 (C3) C3
