KM 7 FAG

Net price:

5.845 €/db

Main warehouse:
Out of stock
0 db

Next delivery:

2024-11-25 - 10 db

Product number:

KM 7

Brand:

FAG

Product name:

locknut

Sizes:

35X52X8


Inquiry Subscribe

Product details from catalogue

Drawings:

KM7 FAG

Housing selection guide

Locknuts KM, main dimensions to DIN 981


G Thread M35x1,5
d2 Outerside diameter 52,00 mm
B Width 8,00 mm
≈m Weight 70,00 g
d1 Chamfer diameter 44,00 mm
b Width retaining slot 5,00 mm
A^a Groove base distance 48,00 mm
F Axial load capacity, static 43.000,00 N
