NUP 214-E-XL-TVP2 FAG

Net price:

101.914 €/pcs

Main warehouse:
On stock
2 pcs

Product number:

NUP 214-E-XL-TVP2

Brand:

FAG

Product name:

bearing

Sizes:

70X125X24

Suffixes:

E - növelt teherbírás

TVP2 - görgõn vezetett polyamid kosár


Replacements:
NUP 214-E-TVP2

Interchange catalog:
11DAVZ RIV 92214 GPZ NUP214 KOYO NUP214 NWG NUP214 RHP NUP214 SNR NUP214 STEYR NUP214ECP SKF NUP214ET NSK NUPL70 FBC NUP214E NTN 06.32580.4600 MAN 0635421233 ZF 44010877 FIAT 44882484 FIAT 5969892 SKC 8135001 SKC SK999000F026 ROVER X620608500 FEND 375216R91 IHC NUP214 NEUW 11DAVZ RIV

Inquiry Subscribe

Product details from catalogue

Drawings:

NUP214-E-XL-TVP2 FAG


d Bore diameter 70 mm
D Outside diameter 125 mm
B Width 24 mm
Cr Basic dynamic load rating, radial 141.000 N
C0r Basic static load rating, radial 138.000 N
Cur Fatigue load limit, radial 24.600 N
nG Limiting speed 7.800 1/min
nϑr Reference speed 4.650 1/min
≈m Weight 1,19 kg
d1 Maximum rib diameter inner ring 89,4 mm
D1 min Minimum rib diameter outer ring 109,4 mm
da min Minimum diameter shaft shoulder 79 mm
dc min Minimum shaft shoulder 92 mm
Da max Maximum diameter of housing shoulder 116 mm
ra max Maximum recess radius 1,5 mm
rmin Minimum chamfer dimension 1,5 mm
r1 min Minimum chamfer dimension 1,5 mm
E Raceway diameter outer ring 113,5 mm
F Raceway diameter inner ring 83,5 mm
B3 Width of loose rib 4 mm
Tmin Operating temperature min. -30 °C
Tmax Operating temperature max. 120 °C
Design Increased Capacity Design E
Cage Solid Window Cage made from PA66 TVP2
Radial internal clearance Group N (CN) CN
Tolerance class Normal (PN) PN
