51144-MP FAG

Net price:

516.079 €/db


Main warehouse:
Out of stock
0 db


Next delivery:

2025-02-07 - 1 db

Product number:

51144-MP

Brand:

FAG

Product name:

bearing

Sizes:

220X270X37


Inquiry Subscribe

Product details from catalogue

Drawings:

51144-MP FAG


d Inner diameter shaft washer 220 mm
D Outer diameter housing washer 270 mm
T Height 37 mm
Ca Basic dynamic load rating, axial 168.000 N
C0a Basic static load rating, axial 730.000 N
Cua Fatigue load limit, axial 21.300 N
nG Limiting speed 1.870 1/min
nϑr Reference speed 1.600 1/min
≈m Weight 4,508 kg
da min Minimum diameter shaft shoulder 250 mm
Da max Maximum diameter of housing shoulder 240 mm
ra max Maximum filled radius 1 mm
rmin Minimum chamfer dimension 1,1 mm
d1 Outer diameter shaft washer 267 mm
Tmin Operating temperature min. -30 °C
Tmax Operating temperature max. 200 °C
A Minimum load factor 3
Cage solid brass cage MP
Tolerance class Normal (PN) PN
