3315-C3 FAG

Net price:

315.042 €/pcs

Main warehouse:
On stock
1 pcs

Product number:

3315-C3

Brand:

FAG

Product name:

bearing

Sizes:

75X160X68.30


Inquiry Subscribe
Angular contact ball bearing 33, double row, with filling slot, steel sheet metal cage

Product details from catalogue

Drawings:

3315-C3 FAG


d Bore diameter 75 mm
D Outside diameter 160 mm
B Width 68,3 mm
Cr Basic dynamic load rating, radial 192.000 N
C0r Basic static load rating, radial 209.000 N
Cur Fatigue load limit, radial 10.000 N
nG Limiting speed 4.400 1/min
nϑr Reference speed 4.250 1/min
≈m Weight 6,16 kg
da min Minimum diameter shaft shoulder 87 mm
Da max Maximum diameter of housing shoulder 148 mm
ra max Maximum fillet radius 2,1 mm
rmin Minimum chamfer dimension 2,1 mm
D1 Shoulder diameter outer ring 141,2 mm
d1 Shoulder diameter inner ring 105,5 mm
a Distance between the apexes of the pressure cones 116,6 mm
α Contact angle 35 °
Tmin Operating temperature min. -30 °C
Tmax Operating temperature max. 150 °C
Lubricant Bearing not greased. Without
Sealing open Without
Cage steel sheet metal J
Tolerance class Normal (PN) PN
Axial internal clearance Group 3 (C3), bigger than CN C3
Dimensional / heat stabilization Rings dimensional stabilized up to 150° S0
Design variant Bearing wiht filling slot FN
