ENB 7015-E-2RSD-T-P4S UL FAG
Net price:
Main warehouse:
466.831 €/pcs
Main warehouse:
On stock
1 pcs
Product details from catalogue
Drawings:
B7015-E-2RSD-T-P4S-UL FAG
| d | Bore diameter | 75 mm |
| D | Outside diameter | 115 mm |
| B | Width | 20 mm |
| Cr | Basic dynamic load rating, radial | 49.500 N |
| C0r | Basic static load rating, radial | 31.000 N |
| Cur | Fatigue load limit, radial | 3.300 N |
| nG Grease | Limiting speed for grease lubrication | 11.000 1/min |
| ≈m | Weight | 0,619 kg |
| da | Diameter shaft shoulder | 82 mm |
| da | Diameter shaft shoulder clearance | h12 |
| Da | Shoulder diameter outer ring | 107 mm |
| Da | Shoulder diameter outer ring clearance | H12 |
| ra max | Maximum recess radius | 1 mm |
| ra1 max | Maximum recess radius | 0,6 mm |
| a | Distance between the apexes of the pressure cones | 32,1 mm |
| rmin | Minimum chamfer dimension | 1,1 mm |
| r1 min | Minimum chamfer dimension | 1,1 mm |
| α | Contact angle | 25 ° |
| Tmin | Operating temperature min. | -30 °C |
| Tmax | Operating temperature max. | 80 °C |
| FV L | Preload force light | 405 N |
| FV M | Preload force medium | 1.430 N |
| FV H | Preload force heavy | 3.005 N |
| KaE L | Lift-off force light | 1.180 N |
| KaE M | Lift-off force medium | 4.305 N |
| KaE H | Lift-off force heavy | 9.353 N |
| ca L | Axial rigidity light | 177 N/µm |
| ca M | Axial rigidity medium | 285 N/µm |
| ca H | Axial rigidity heavy | 387 N/µm |
| Contact angle | Contact angle 25° | E |
| Lubricant | Standard | |
| Sealing | non-contact sealed on both sides and greased “for life” | 2RSD |
| Outer shape | Standard | |
| Cage | Laminated fabric cage | T |
| Tolerance class | tolerance class P4S, FAG standard better than P4 to DIN 620 | P4S |
| Arrangement bearing set | Single bearing | U |
| Preload | preload light | L |
