UKFL 208-J7 FAG

Net price:

35.717 €/pcs

Main warehouse:
On stock
4 pcs

Product number:

UKFL 208-J7

Brand:

FAG

Product name:

housing unit

Sizes:

35X175X46


Inquiry Subscribe

Product details from catalogue

Drawings:

UKFL208-J7 FAG

Flanged housing unit UKFL


d Bore diameter 35 mm
L Flange width 100 mm
H Height flange 175 mm
Cr Basic dynamic load rating, radial 34.500 N
C0r Basic static load rating, radial 19.800 N
Cur Fatigue load limit, radial 1.030 N
≈m Weight 1,57 kg
J Distance fixing bore 144 mm
N Fixing bore 16 mm
n Number of screwing holes 2
A1 Thickness of flange 16 mm
A2 Distance raceway 21 mm
B Width 31 mm
B1 Locking collar total width 46 mm
d3 Outside diameter eccentric locking collar 58 mm
