7315-B-XL-JP-UA FAG

Net price:

236.909 €/pcs

Main warehouse:
On stock
2 pcs

Product number:

7315-B-XL-JP-UA

Brand:

FAG

Product name:

bearing

Suffixes:

UA - univerzális kivitel párosított beépítéshez, a csapágypárnak "O"- és "X"-elrendezésben történõ beépítésnél csekély axiális hézaga van


Replacements:
7315 BECBJ

Inquiry Subscribe

Product details from catalogue

Drawings:

7315-B-XL-JP-UA FAG


d Bore diameter 75 mm
D Outside diameter 160 mm
B Width 37 mm
Cr Basic dynamic load rating, radial 140.000 N
C0r Basic static load rating, radial 107.000 N
Cur Fatigue load limit, radial 6.900 N
nG Limiting speed 5.600 1/min
nϑr Reference speed 4.500 1/min
≈m Weight 3,3 kg
da min Minimum diameter of shaft shoulder 87 mm
Da max Maximum diameter of housing shoulder 148 mm
Db max Maximum diameter of housing shoulder 153 mm
ra max Maximum fillet radius of shaft 2,1 mm
ra1 max Maximum fillet radius of housing 1 mm
rmin Minimum chamfer dimension 2,1 mm
r1 min Minimum chamfer dimension 1,1 mm
D1 Shoulder diameter on outer ring wide side face 128 mm
d1 Shoulder diameter on inner ring wide side face 109,2 mm
a Distance between the apexes of the pressure cones 68 mm
α Contact angle 40 °
Tmin Operating temperature min. -30 °C
Tmax Operating temperature max. 150 °C
Amin Axial clearance per set min. 50 µm
Tol(+) Tolerance for axial clearance or preload per set 12 µm
Design variant Design variant B B
Sealing not sealed Without
Cage steel sheet metal JP
Tolerance class Normal (PN) PN
Bearing with matched conditions for fitting in pairs bearing set with small axial internal clearance UA
Lubricant Bearing not greased. Without
Dimensional / heat stabilization Rings dimensional stabilized up to 150° S0
