6203-C-C4 FAG

Net price:

3.530 €/pcs

Main warehouse:
On stock
11 pcs

Product number:

6203-C-C4

Brand:

FAG

Product name:

bearing

Suffixes:

C - C generáció :50%-al alacsonyabb zaj, 35%-al kisebb súrlódást, P5 futáspontosság, szegecselt acélkosár

C4 - a csapágyhézag nagyobb a C3-nál


Replacements:
6203-C4

Inquiry Subscribe

Product details from catalogue

Drawings:

6203-C-C4>V FAG

Deep groove ball bearing 62..-C, single row, Generation C, steel sheet metal cage


d Bore diameter 17,00 mm
D Outside diameter 40,00 mm
B Width 12,00 mm
Cr Basic dynamic load rating, radial 11.000,00 N
C0r Basic static load rating, radial 4.750,00 N
Cur Fatigue load limit, radial 330,00 N
nG Limiting speed 29.000,00 1/min
nϑr Reference speed 20.100,00 1/min
≈m Weight 0,06 kg
da min Minimum diameter shaft shoulder 21,20 mm
Da max Maximum diameter of housing shoulder 35,80 mm
ra max Maximum fillet radius 0,60 mm
rmin Minimum chamfer dimension 0,60 mm
D2 Caliber diameter outer ring 34,80 mm
d2 Caliber diameter inner ring 22,80 mm
Tmin Operating temperature min. -30,00 °C
Tmax Operating temperature max. 120,00 °C
f0 Calculation factor 13,00
Version code Not marked on bearing >V
Changed internal design GenerationC C
Cage steel sheet metal JN
Tolerance class Class6 (P6), better than PN P6
Dimensional / heat stabilization Rings dimensional stabilized up to 120° SN
Radial internal clearance Group 4 (C4), bigger than C3 C4
Bore type Cylindrical Z
