29416-E1-XL FAG

Net price:

495.727 €/pcs

Main warehouse:
On stock
2 pcs

Product number:

29416-E1-XL

Brand:

FAG

Product name:

bearing

Sizes:

80X170X54

Suffixes:

E1 - növelt teherbírás



Interchange catalog:
29416 FLT 29416 NSK 29416 NTN 29416 SKF 29416 ZKL 29416B KOYO 29416B SKF 29416E SKF 29416E STEYR 9039416 GPZ PO80 RIV

Inquiry Subscribe

Product details from catalogue

Drawings:

29416-E1-XL FAG


d Bore diameter 80 mm
D Outside diameter 170 mm
T Height 54 mm
Ca Basic dynamic load rating, axial 720.000 N
C0a Basic static load rating, axial 1.720.000 N
Cua Fatigue load limit, axial 199.000 N
nG Limiting speed 4.350 1/min
nϑr Reference speed 2.140 1/min
≈m Weight 5,32 kg
da min Minimum diameter shaft shoulder 125 mm
Da max Maximum diameter of housing shoulder 141 mm
db max Maximum distance sleeve 88 mm
ra max Maximum recess radius 2,1 mm
d1 Rip diameter shaft washer 150,9 mm
rmin Minimum chamfer dimension 2,1 mm
T3 Height of the shaft washer 35 mm
T5 Distance shaft washer - cage 48,5 mm
A Distance of the center point 50 mm
Tmin Operating temperature min. -30 °C
Tmax Operating temperature max. 200 °C
Cage Sheet metal cage JP
Locating feature, shaft washer Without
Handling thread holes Without
Heat treatment Standard
Constricted width and inclination variation Standard
Test certificate Without
