NJ 1007-XL-M1-C3 FAG

Net price:

63.429 €/pcs

Main warehouse:
On stock
1 pcs

Product number:

NJ 1007-XL-M1-C3

Brand:

FAG

Product name:

bearing

Suffixes:

M1 - görgõn vezetett bronz kosár.zsírkenéshez javasolt

C3 - a csapágyhézag nagyobb a normálisnál


Replacements:
NJ 1007-M1-C3*FAG

Inquiry Subscribe

Product details from catalogue

Drawings:

NJ1007-XL-M1-C3 FAG


d Bore diameter 35 mm
D Outside diameter 62 mm
B Width 14 mm
Cr Basic dynamic load rating, radial 29.000 N
C0r Basic static load rating, radial 26.000 N
Cur Fatigue load limit, radial 3.850 N
nG Limiting speed 22.700 1/min
nϑr Reference speed 9.700 1/min
≈m Weight 182 g
da min Minimum diameter shaft shoulder 38 mm
da max Maximum diameter of shaft shoulder 41 mm
Da max Maximum diameter of housing shoulder 57 mm
dc min Minimum shaft shoulder 45 mm
ra max Maximum recess radius 1 mm
rmin Minimum chamfer dimension 1 mm
r1 min Minimum chamfer dimension 0,6 mm
s Axial displacement 1,85 mm
E Raceway diameter outer ring 55 mm
F Raceway diameter inner ring 42 mm
D1 min Minimum rib diameter outer ring 52,4 mm
d1 Maximum rib diameter inner ring 44,7 mm
Tmin Operating temperature min. -30 °C
Tmax Operating temperature max. 150 °C
Design Standard
Cage Two Piece Brass Cage Roller Guided M1
Radial internal clearance Group 3 (C3) C3
Tolerance class Normal (PN) PN
