51201 FAG

Net price:

9.688 €/pcs

Main warehouse:
On stock
22 pcs

Product number:

51201

Brand:

FAG

Product name:

bearing

Sizes:

12X28X11


Interchange catalog:
12TA12 ISO 51201 FBC 51201 FLT 51201 NSK 51201 NTN 51201 SKF 51201 SNR 51201 STEYR 51201 ZKL 51201MG KOYO 8201 GPZ LP12 RIV 0635360016 ZF 181526 VOLVO 26801250 FIAT 274053602 LIEB 3011175 SKC 5948284 SKC 6600051 VOLVO 680125 FIAT 12TA12 ISO 000711051201 MTU LP12 RIV 51201 STEY

Inquiry Subscribe

Product details from catalogue

Drawings:

51201 FAG

Axial deep groove ball bearing 512, single direction, steel sheet metal cage


d Inner diameter shaft washer 12,00 mm
D Outer diameter housing washer 28,00 mm
T Height 11,00 mm
Ca Basic dynamic load rating, axial 13.200,00 N
C0a Basic static load rating, axial 19.000,00 N
Cua Fatigue load limit, axial 870,00 N
nG Limiting speed 11.300,00 1/min
nϑr Reference speed 16.900,00 1/min
≈m Weight 30,00 g
da min Minimum diameter shaft shoulder 22,00 mm
Da max Maximum diameter of housing shoulder 18,00 mm
ra max Maximum filled radius 0,60 mm
rmin Minimum chamfer dimension 0,60 mm
d1 Outer diameter shaft washer 28,00 mm
Tmin Operating temperature min. -30,00 °C
Tmax Operating temperature max. 150,00 °C
A Minimum load factor 0,00
Cage steel sheet metal J
Tolerance class Normal (PN) PN
