ENQJ 306 XL-MPA FAG
Net price:
Main warehouse:
55.797 €/pcs
Main warehouse:
On stock
4 pcs
Product number:
QJ 306 XL-MPA
Brand:
Product name:
bearing
Sizes:
30X72X19
Suffixes:
MP - réz ablakos tömörkosár, görgõn vezetett
MPA - réz ablakos tömörkosár, külsö gyürün vezetett
Replacements:
QJ 306 MPA 712136410Interchange catalog:
6306BI KOYO 9306U MRC 9306UP MRC QJ306 RHP QJ306 SKF QJ306MA SKF QJ306MA SNR QJ306MPA STEYR QJ306 RHP 000628300030 DAG 0009812327 DAG 0635340017 ZF 37205069183 FAUN 5069183 FAUN 900.9.0824.71 GETR 900.9.824.71 GETRInquiry Subscribe
Product details from catalogue
Drawings:
QJ306-XL-MPA FAG
| d | Bore diameter | 30 mm |
| D | Outside diameter | 72 mm |
| B | Width | 19 mm |
| Cr | Basic dynamic load rating, radial | 57.000 N |
| C0r | Basic static load rating, radial | 38.500 N |
| Cur | Fatigue load limit, radial | 2.700 N |
| nG | Limiting speed | 19.600 1/min |
| nϑr | Reference speed | 7.800 1/min |
| ≈m | Weight | 0,403 kg |
| da min | Minimum diameter shaft shoulder | 37 mm |
| Da max | Maximum diameter of housing shoulder | 65 mm |
| ra max | Maximum fillet radius | 1 mm |
| rmin | Minimum chamfer dimension | 1,1 mm |
| D1 | Shoulder diameter outer ring | 58 mm |
| d1 | Shoulder diameter inner ring | 44 mm |
| a | Distance between the apexes of the pressure cones | 36 mm |
| α | Contact angle | 35 ° |
| Tmin | Operating temperature min. | -30 °C |
| Tmax | Operating temperature max. | 150 °C |
| Cage | solid brass cage, outer ring guided | MPA |
| Design, bearing outer ring | Standard | S |
| Coating | Without | |
| Tolerance class | Normal (PN) | PN |
| Dimensional / heat stabilization | Rings dimensional stabilized up to 150° | S0 |
| Axial internal clearance | Group N (CN) | CN |
