QJ 208-XL-N-TVP FAG

Net price:

69.722 €/pcs

Main warehouse:
Out of stock
0 pcs

Product number:

QJ 208-XL-N-TVP

Brand:

FAG

Product name:

bearing

Suffixes:

N - palásthorony a rögzítõgyûrûnek

TVP - polyamid kosár, görgõn vezetett

XL,X-life - a futófelületek, gördülõelemek optimalizálásával megnövelt élettartam


Replacements:
QJ 208-N-TVP*FAG

Inquiry Subscribe

Product details from catalogue

Drawings:

QJ208-XL-N-TVP FAG


d Bore diameter 40 mm
D Outside diameter 80 mm
B Width 18 mm
Cr Basic dynamic load rating, radial 58.000 N
C0r Basic static load rating, radial 46.500 N
Cur Fatigue load limit, radial 3.250 N
nG Limiting speed 11.600 1/min
nϑr Reference speed 7.500 1/min
≈m Weight 385 g
da min Minimum diameter shaft shoulder 47 mm
Da max Maximum diameter of housing shoulder 73 mm
ra max Maximum fillet radius 1 mm
rmin Minimum chamfer dimension 1,1 mm
D1 Shoulder diameter outer ring 66,8 mm
d1 Shoulder diameter inner ring 53,7 mm
a Distance between the apexes of the pressure cones 42 mm
α Contact angle 35 °
Tmin Operating temperature min. -30 °C
Tmax Operating temperature max. 120 °C
Cage solid cage made of glass-fiber reinforced polyamid PA66 TVP
Design, bearing outer ring Ring groove for snap ring N
Coating Without
Tolerance class Normal (PN) PN
Dimensional / heat stabilization Rings dimensional stabilized up to 150° S0
Axial internal clearance Group N (CN) CN
