ENHM 803146/10 KOYO
Net price:
Main warehouse:
External stock:
22.683 €/pcs
Main warehouse:
On stock
92 pcs
External stock:
On stock
8 pcs
Next delivery:
2026-02-26 - 40 pcs
Product number:
HM 803146/10
Brand:
Product name:
bearing
Sizes:
41.275X88.9X29.37/23.02
Replacements:
NP 784953/NP 396414 42471125 IVECO 0019806902 MERCEDES 803146/10 42471125 7162215 IVECO 2d0525251A 38120-8S100 NISSAN HM 803146/2/110/2 QCL7C HM 803146/2 QCL7C/110/2 QCL7 SET330Interchange catalog:
K-HM803146/K-HM803110 SKF HM803146-HM803110 TIMK HM803146/110 KOYO 1487681 CHRY 0009816005 DB 0019810005 DB 48344/72/35-47 DB 48344/72/35-80 DB 7162215 FIAT 8HA-023-2 GKN 91007312 GM 1496374 IVECO 32087 NEWH 291525251 VAG 0735370557 ZF 0735370732 ZF 0750117341 ZFInquiry Subscribe
Replacements
| Photo | Product number | Sizes | Stock |
|---|---|---|---|
|
NP 784953/NP 396414*TIM | 41.275X88.9X29.37/23.02 |
|
|
|
4T-HM 803146/10*NTN | 41.275X88.9X29.37/23.02 |
|
Product details from catalogue
Drawings:
| d | 41.275 mm |
| D | 88.900 mm |
| T | 30.162 mm |
| B | 29.370 mm |
| C | 23.020 mm |
| r(min.) | 3.6 mm |
| r1(min.) | 3.2 mm |
| Basic load ratings : Cr | 124 kN |
| Basic load ratings : C0r | 125 kN |
| Fatigue load limit : Cu | 18.5 kN |
| Limiting speeds(Grease lub.) | 4600 min-1 |
| Limiting speeds(Oil lub.) | 6100 min-1 |
| Load center spread : a | 26.1 mm |
| Constant :e | 0.55 |
| Axial load factors : Y1 | 1.10 |
| Axial load factors : Y0 | 0.60 |
| da | 60.0 mm |
| db | 53.0 mm |
| Da | 74.0 mm |
| Db | 85.0 mm |
| ra(max.) | 3.6 mm |
| rb(max.) | 3.2 mm |
| (Refer.)Mass | 0.892 kg |
