NJ 408-XL-M1 FAG

Net price:

230.379 €/pcs

Main warehouse:
On stock
2 pcs

Product number:

NJ 408-XL-M1

Brand:

FAG

Product name:

bearing

Sizes:

40X110X27

Replacements:
NJ 408-M1

Interchange catalog:
NJ408M RHP

Inquiry Subscribe

Product details from catalogue

Drawings:

NJ408-XL-M1 FAG

Cylindrical roller bearing NJ..-M1, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ


d Bore diameter 40,00 mm
D Outside diameter 110,00 mm
B Width 27,00 mm
Cr Basic dynamic load rating, radial 119.000,00 N
C0r Basic static load rating, radial 95.000,00 N
Cur Fatigue load limit, radial 17.100,00 N
nG Limiting speed 12.100,00 1/min
nϑr Reference speed 6.500,00 1/min
≈m Weight 1,46 kg
da min Minimum diameter shaft shoulder 53,00 mm
da max Maximum diameter of shaft shoulder 57,00 mm
Da max Maximum diameter of housing shoulder 97,00 mm
dc min Minimum shaft shoulder 67,00 mm
ra max Maximum recess radius 2,00 mm
rmin Minimum chamfer dimension 2,00 mm
r1 min Minimum chamfer dimension 2,00 mm
s Axial displacement 2,80 mm
E Raceway diameter outer ring 92,00 mm
F Raceway diameter inner ring 58,00 mm
D1 min Minimum rib diameter outer ring 86,40 mm
d1 Maximum rib diameter inner ring 64,60 mm
Tmin Operating temperature min. -30,00 °C
Tmax Operating temperature max. 150,00 °C
Design Standard
Cage Two Piece Brass Cage Roller Guided M1
Radial internal clearance Group N (CN) CN
Tolerance class Normal (PN) PN
